ASTM D1267 LPG Vapour Pressure Tester for Liquefied Petroleum Gas

    • ASTM D1267 LPG Vapour Pressure Tester for Liquefied Petroleum Gas
    • ASTM D1267 LPG Vapour Pressure Tester for Liquefied Petroleum Gas
    • ASTM D1267 LPG Vapour Pressure Tester for Liquefied Petroleum Gas
  • ASTM D1267 LPG Vapour Pressure Tester for Liquefied Petroleum Gas

    Подробная информация о продукте:

    Место происхождения: КИТАЙ
    Фирменное наименование: AI
    Сертификация: ISO
    Model Number: AIC-1267

    Оплата и доставка Условия:

    Количество мин заказа: 1 набор
    Цена: Договоренно
    Упаковывая детали: Фанерный чехол
    Время доставки: 20 дней
    Условия оплаты: Western Union, T/T, L/C
    Поставка способности: 20 комплектов в месяц
    Контакт
    Подробное описание продукта
    Test Standard: GB/T6602 ASTM D1267 ISO 256 Temperature control: Import PID digital thermostat
    Temperature controlling accuracy: Ambient~70±0.1℃ Oscillation mode: Automatic horizontal oscillation without manual operation
    Pressure correction: Externally can be connected to a precision pressure regulator, internally equipped with fine-tuning function Источник питания: AC220V/50Hz
    Общая мощность: 1,5 кВт Dimension: 900*400*460mm
    Масса: 48 кг Гарантия: 1 год
    Цвет: Белый

    ASTM D1267 LPG Vapour Pressure Tester

    Introduction
    This instrument is mainly suitable for detecting liquefied petroleum gas whose boiling point is higher than 0℃, hydrocarbon volume content is less than 5%, and its vapor pressure is not more than 1550KPA at 37.8℃. When the instrument is used,the cooled sample is filled into the oxygen bomb of the vapor pressure tester, and the oxygen bomb is connected with the gas detector.

    I.Main features
    ◆Imported Omron PID temperature controller, digital continuous display temperature, accuracy 0.1℃
    ◆The instrument is made of cold-rolled steel plate, and the surface is treated with electrostatic spray, which is corrosion-resistant
    and easy to clean.
    ◆Instrument welding adopts butt welding technology, no solder joints, beautiful and generous.
    ◆The instrument adopts imported pressure transmitter with high pressure display accuracy.
    ◆All stainless steel inner tank of water bath to prevent rust.
    ◆Imported quick connector, plug and use, no leakage, easy operation.



    II.Technical specification
    Model
    AIC-1267
    Applicable Standard
    GB/T6602 ASTM D1267 ISO 256
    Temperature control
    Import PID digital thermostat
    Temperature controlling accuracy
    Ambient70±0.1
    Oscillation mode
    Automatic horizontal oscillation without manual operation
    Working units
    2 bombs
    Pressure correction

    Externally can be connected to a precision pressure regulator,
     internally equipped with fine-tuning function
    Power supply
    1.5KW
    Dimension
    900*400*460mm
    Weight
    48KG
    Color White



    II.Accessories list
    No.
    Name
    Quantity
    Unit
    1
    Main unit
    1
    Set
    2
    Fuse 20A
    4
    PCS
    3
    Test bomb
    2
    Set
    4
    User manual
    1
    Copy
