Characteristic

◆Plexiglass spray box for easy observation;

◆Precision pressure gauge shows spray pressure;

◆Stainless steel plate meets standard requirements: 152.4×50.75×6.35mm;

◆Stainless steel mold meets standard requirements: 203.2×76.2×11.11mm;

◆Stainless steel nozzle, nozzle diameter: Φ3.18mm;

◆The front end of the pressure gauge has a bypass valve to adjust the pressure: 40psi±1psi;

◆Microcomputer temperature controller, digital display, accuracy ±0.2℃, PT100 sensor;

◆The magnetic pump circulates the cooling medium, and the circulation pipe is equipped with an insulation sleeve;

◆Digital display timer to control spray time.

Technical specifications

1. Applicable standard:ASTM D4049,SH/T0643

2. Heating method of Water Spray Resistance Tester:electrical tube

3. Timing method:digital timer

4. Temperature control method:digital PID controller

5. Working temperature:38±0.2℃

6. Working hydraulic pressure of Water Spray Resistance Instrument:40psi±1psi

7. Hydraulic pressure control:adjusted by bypass valve

8. Spray method:precise nozzle

9. Total power:2.5KW

10. Power supply:AC220V/50Hz

11. Weight:43KG
