Automatic Fraass Method Breaking Point Testing Equipment for Asphalt

Подробная информация о продукте:

Место происхождения:	КИТАЙ
Фирменное наименование:	AI
Сертификация:	ISO
Номер модели:	BPT

Оплата и доставка Условия:

Количество мин заказа:	1 ПК
Цена:	Договоренно
Упаковывая детали:	Фанерный чехол
Время доставки:	10 дней
Условия оплаты:	Т/Т, Вестерн Юнион
Поставка способности:	1000 pc/month

Контакт

Подробное описание продукта

Test method:	Frass method	Temperature meauring range:	-30℃～25℃
Блоки деятельности:	3 шт	Steel slice:	41mm×20mm×0.15mm
Энергопотребление:	2050W	Power supply:	AC (220 ± 5%) V, 50Hz
Size:	500mm×400mm×570mm	Гарантия:	1 год

Automatic Fraass Method Breaking Point Testing Equipment

Name: Automatic Fraass Method Breaking Point Testing Equipment for Asphalt
Brand: Advanced Instruments Co.,Ltd
SKU: BPT
Availability: InStock

Automatic Fraass Method Breaking Point Testing Equipment for Asphalt

Summary

This breaking point testing equpment is used to determine the temperature which a bitumen tends to break rather to flow when cooled and stressed as per standards GB/T 4510 and JTG E20-2011. It can do three tests at the same time in the same environment and calculate the average value. The cooling rate is controlled by computer.

I. Main technical features

The frass method breaking point testing equipment is controlled by micro computer. The cooling rate is controlled automatically. It automatically timing to bend samples. The test data is shown on the colored LCD and outputted by built-in printer.

II.Specifications:

1	Power supply	AC(220±10%)V,50Hz
2	Refrigeration mode	Low temperature circulatory bath
3	Cooling rate	(1±0.5)℃/min
4	Temperature measuring range	-30℃～25℃
5	Temperature measuring error	±0.5℃
6	Steel slice	41mm×20mm×0.15mm
7	Test samples	It can determine 3 samples at the same time.
8	Ambient temperature	Room temp. ～+30℃
9	Relative humidity	≤85%
10	Power consumption	450W(breaking point tester)+ 1600W(low temperature circulatory bath)
11	Overall dimension	500mm×400mm×570mm(breaking point tester)

Note: We can customize the breaking point tester with measuring range:-40℃～25℃

III.Accessories

No.	Name	Unit	Qty	Memo
1	Automatic Breaking Point Tester	Set	1
2	CWB-15 Low Temperature Cyclic Thermostatic Water Bath	Set	1
3	Stainless steel sample piece	Piece	6
4	Rubber pipe(Ф10×1 meter)	Piece	2
5	Insulated sponge pipe(Ф15×1 meter)	Piece	2
6	Operation manual	Piece	1
7	Low temperature cyclic thermostatic water bath usage	Piece	1
