Automatic Abel Closed Cup Flash Point Test Set
Introduction
This Abel Closed-cup Flash Point Test Set is our new product,which is strictly designed with different test modes for different test standards.It can test many items and automation degree is very high.It can be widely used for many industries,such as chemicals safety inspecting,petro-chemical inspection and plastic.
I.Main features
- Test model options:it's strictly operated as per different standards of Abel Closed Cup to detect flash point of sample:
A.ISO13736,ISO1516,ISO1523 ,GB/T 21789 etc;
B.Expected flash point searching:perform rapid test for sample with unknown expected flash point and search it;
C.User defined
(Temperature rising controlling and ingtion test modes are differently required in each standards,users can set test model by themself.)
- High automation:Set flash point test parameters according to operation ways shown on LCD screen,press "Start" key,all test process will be done automatically.
- Colorful touch screen can operated directly and display whole test process clearly.The interface is simple,operation is easy.
- This abel fash point tester is compact,small and beautiful
- This Abel closed cup appartus has function of fault diagnosis and alarming
- The test result can be printed out by standard needle printer.
II.Technical specifications
| 1 |
Applicable standards |
ISO 13736, IP170, ISO 1516, ISO 1523, GB/T 21789 |
| 2 |
Structure |
Desktop,with full stainless steel case |
| 3 |
Measuring range |
10℃ ～110℃ ,temperature controlling accuracy ±0.1 ℃
|
| 4 |
Refrigeration source |
inbuilt imported semiconductor refrigeration metal bath cold trap |
| 5 |
Stirring way |
0～30rpm,adjustable |
| 6 |
Temperature sensor |
PT100 |
| 7 |
Flash point detection sensor |
CRC thermal couple
|
| 8 |
Display |
Colorful touch screen |
| 9 |
Ignition method |
Automatic(gas ignition and electronic ignition can be chose by actual requirements),adopting high sensitivity thermal couple detection method |
| 10 |
Display content |
①controlling temperature and set expected flash point
②fault prompt screen
③parameters and pressure setting
|
| 11 |
Power consumption |
800W |
| 12 |
Overall size |
400(W)×380(D)×350(H) mm |
| 13 |
Weight |
20KG |
Picture of Abel-R6 Automatic Abel Closed Cup Flash Point Test SEt
