Introduction

This H2S tester is fully designed according to requirements of ASTM and IP standards.Dilute few sample with dilution,heat the sample to 60℃ with metal bath being controlled under precise temperature,and release H2S in sample.Using clean air as carrier gas,carry H2S into measuring cell of electro-chemical sensor,and get the instant concentration of H2S.Air flow is measured and controlled by digital mass flow meter,and when H2S in sample is released completely,the instrument can calculate the cumulative concentration of H2S.

Main Feasture

◆ Computer control, automatic measurement and automatic calculation results;

◆ Air flow is measured and controlled by digital mass flowmeter;

◆ The H2S Hydrogen Sulfide Content Tester is designed and manufactured according to the requirements of ASTM and IP test standards;

◆ Gas phase processor for semiconductor refrigeration, with fast cooling speed;

◆ Customized fisher type glass reaction tube, easy to operate;

◆ Luer type sintered filter, filled with special adsorbent;

◆ The H2S Hydrogen Sulfide Content Tester adopts imported H2S200 detection system, which can read directly;

◆ Quick screening gland, self sealing.

Technical Specifications

• Applicable standard:ASTM D7621,ISO 8217, IP570
• Measuring range:0-250mg/kg H2S
• Working temperature: 15-30℃,RH80%
• Viscosity range:reach 3000mm2/s
• Test time:15 minutes
• Measuring method:electro-chemical sensor
• Sample quantity:1ml,2ml,5m(depends on concentration of H2S)
• Dilution quantity:20ml
• Power supply:AC220V±10V 50Hz
• Power consumption:300W

Main Configuration
